160 × 120 resolution (thermal), and 8 MP resolution (optical) DDE,3D DNR, and adaptive AGC 640 × 480 resolution 3.5” LCD touch display Up to five hours continuous running Temperature measurement range: 30°C to 45°C Temperature measurement accuracy: ±0.5°C
Thermal Image SensorVOx Uncooled Focal Plane Arrays Resolution160×120 Pixel Interval17μm Response Waveband8μm to 14μm NETDLess than 40 mK (@25°C,F#=1.1) Focal Length6.2mm Focus ModeManual Field Of View25° × 18.7° IFOV2.74 mrad Image Frequency25 hz ApertureF 1.1
Optical Picture ResolutionConfigurable: 2 MP, 5 MP, 8 MP Video Resolution640 × 480
Image Display Monitor640 × 480 resolution 3.5-inch LCD touch display Image ModeThermal view, B/W optical view, image fusion view are selectable PalettesBlack hot, White hot, Red hot, Rainbow, Ironbow, Fusion, Rain Image FusionFusion view of thermal view and overlaid details of the optical channel Digital ZoomThermal：1×, 2×, 4×
System Function Laser LightSupport (Point to the thermography target) CaptureThermal/Optical/Fusion image VideoThermal/Optical/Fusion image Text CommentYes Voice CommentYes Wi-FiYes StorageBuilt-in memory module (16 G) ClientiVMS-4800 (PC);Hik-Thermal (Mobile APP) Battery TypeDismountable and rechargeable Li-ion Battery Battery Operating Time5 hours in normal temperature, with Wi-Fi, Bluetooth, and supplement light off. 4 hours in normal temperature, with Wi-Fi, Bluetooth, and supplement light on.
General Hardware InterfaceType-C USB Power Supply5 VDC/2 A Power ConsumptionMax. 4.5 W Working Temperature-10 °C to 50 °C (14 °F to 122 °F) Protection LevelIP54 Drop Test Height2 m (6.56 feet) WeightWith Battery: 653 g (1.44 lb) Without Battery: 511 g (1.13 lb) Dimension244 mm × 100 mm × 104 mm (9.6 ″ × 3.9 ″ × 4.1 ″)
|
